Delano 800x500mm Matt Black Heated Towel Rail – Compact Designer Radiator, Central Connection

Designed for the spaces standard ladder rails don't suit, the Delano 800x500mm matt black heated towel rail is a compact designer radiator with a distinctive 6+1 bar layout and neat 80mm central connections — the valves sit close together beneath the rail for a cleaner, more architectural look than traditional side-entry rails. At 800mm high it fits under windows, beside vanities and in cloakrooms where a 1200mm rail would overwhelm the wall.

Delano Matt Black Towel Radiator – Key Specifications

• Dimensions: 800mm (H) x 500mm (W) x 124mm (D)
• Bars: 6+1 designer layout
• Finish: Textured matt black powder coat
• Material: Low-carbon mild steel
• Heat output: 304W / 1,037 BTU (ΔT50) · 383W / 1,307 BTU (ΔT60)
• Recommended room size: Up to 3m², or as a towel warmer alongside other heating
• Pipe centres: 80mm central connection · Connections: 1/2" BSP
• Water content: 2.85L · Max working pressure: 4 bar (tested to 5.2 bar) · Max temp: 95°C
• Weight: 7.85kg · Vertical wall-mounted installation for central heating systems

Why Choose the Delano?

Comparable 800mm designer black rails at national retailers sit around £160–£200 — the Delano delivers the compact designer look with a proper 95°C temperature rating for less. The 80mm central connection is a modern plumbing standard that keeps pipework tidy and symmetrical, ideal for new builds and full renovations. Match it with black tiles or contrast against white tiles, and see the full designer heated towel rails collection. Need a taller matt black rail? See the Azzano 1200x500.

Frequently Asked Questions

What does "central connection" mean?

Instead of valves at each side of the rail, both flow and return connect at the centre-bottom, 80mm apart. It looks neater and simplifies pipework planning on new installations.

Is an 800mm towel rail big enough?

For cloakrooms, en-suites and compact bathrooms up to around 3m², yes — 304W (1,037 BTU) at ΔT50 keeps the room warm and towels dry. In larger bathrooms use it alongside underfloor heating.

What is the 6+1 bar layout?

Six main bars plus an additional rail, giving grouped hanging sections rather than an evenly spaced ladder — part of its designer look and practical for separating bath and hand towels.

Can I use it on a sealed system?

Yes — 4 bar maximum working pressure (tested to 5.2 bar) and rated to 95°C water temperature.
